PRODUCTS
EVA ROUND FIXED SERIES
Low-Glare Recessed Fixed Downlight
Power: 10W
Colour Temperature: 3000K
CRI: >90
Lumen Output: 800lm
Beam Angle: 60°
Dimension: ⌀88mm x H53mm
Cut-out: ⌀75mm
Colour: White (Housing) + Black (Reflector)
Control: On/Off
Power: 10W
Colour Temperature: 4000K
CRI: >90
Lumen Output: 800lm
Beam Angle: 60°
Dimension: ⌀88mm x H53mm
Cut-out: ⌀75mm
Colour: White (Housing) + Black (Reflector)
Control: On/Off
EVA ROUND ADJUSTABLE SERIES
Low-Glare Recessed Adjustable Downlight
Power: 10W
Colour Temperature: 3000K
CRI: >90
Lumen Output: 1100lm
Beam Angle: 36°
Dimension: ⌀83mm x H85mm
Cut-out: ⌀75mm
Colour: White (Housing) + Black (Reflector)
Control: On/Off
Power: 10W
Colour Temperature: 4000K
CRI: >90
Lumen Output: 1100lm
Beam Angle: 36°
Dimension: ⌀83mm x H85mm
Cut-out: ⌀75mm
Colour: White (Housing) + Black (Reflector)
Control: On/Off
FLEXI STRIP SERIES
Dot-less COB LED Strip
Power: 6W/m
Colour Temperature: 3000K/4000K
Lumen Output: 520lm/m
Voltage (V): DC24
Beam Angle: 180°
IP: 20
Size: L5000*W5*H2mm
Cutting Length: 20mm
Power: 10W/m
Colour Temperature: 3000K/4000K
Lumen Output: 1000lm/m
Voltage (V): DC24
Beam Angle: 180°
IP: 20
Size: L5000*W8*H2mm
Cutting Length: 50mm
Power: 60W
Input Voltage: 198-242V AC
Output Frequency: 50/60Hz
Output Current: 2.5A
Output Voltage: DC24V
Control: Non-dimmable
Dimension: L130*W53*H27mm
IP: 20
Power: 150W
Input Voltage: 198-242V AC
Output Frequency: 50/60Hz
Output Current: 6.25A
Output Voltage: DC24V
Control: Non-dimmable
Dimension: L210*W53*H27mm
IP: 20
ACOUSTIC LIGHTING
Low-Glare Recessed Adjustable Downlight
Power: 10W
Colour Temperature: 3000K
CRI: >90
Lumen Output: 1100lm
Beam Angle: 36°
Dimension: ⌀83mm x H85mm
Cut-out: ⌀75mm
Colour: White (Housing) + Black (Reflector)
Control: On/Off
Power: 10W
Colour Temperature: 4000K
CRI: >90
Lumen Output: 1100lm
Beam Angle: 36°
Dimension: ⌀83mm x H85mm
Cut-out: ⌀75mm
Colour: White (Housing) + Black (Reflector)
Control: On/Off
